Products
EzCiclo Key Material Licensing
RSE103
Description
EzCiclo Key Material- Features
- Process: Pultrution / Filament Winding
- Epoxy Equivalent Weight: 200-250 (g/eq)
- Viscosity (cps): 1,500-2,500 (50℃)
- Recommended Ratio: >10%
Product Profile
| Application | Addition Ratio (in A part) | Mix Viscosity (25°C) | Pot Life (25°C) | Tg-DMA |
|---|---|---|---|---|
| Filament Winding | 12% | 800-1,200 cps | >8 hrs | >105°C |
| Application | Addition Ratio (in A part) | Mix Viscosity (25°C) | Gel Time (Hot plate,150℃, 0.5g) | Tg-DSC |
|---|---|---|---|---|
| Pultrusion | 30% | 800-1,500 cps | 1.2-1.6 mins | 110-125°C |
Equivalent Mechanical Performance to Commercial Thermosetting Epoxy Resin
| Property | Commercial Thermosetting Epoxy Resin | EzCiclo RB507 |
|---|---|---|
| 0°Tensile Strength (MPa) | 1,793 | 1,949 |
| 0°Tensile Modulus (GPa) | 143 | 143 |
| Elongation (%) | 1.21 | 1.28 |
| 0°Compressive Strength (MPa) | 982 | 1,048 |
| 0°Compressive Modulus (GPa) | 132 | 134 |
| Elongation(%) | 0.77 | 0.82 |
| 0°Flexural Strength (MPa) | 1,755 | 1,629 |
| 0°Flexural Modulus (GPa) | 145 | 144 |
| Elongation(%) | 1.19 | 1.12 |
| ILSS (MPa) | 66 | 64 |
