EzCiclo Key Material Licensing
RSE104
Description
EzCiclo Key Material- Features
- Process: Wind Power Infusion
- Epoxy Equivalent Weight: 235-265 (g/eq)
- Viscosity (cps): 450-750 (25℃)
- Recommended Ratio: >10%
Product Profile
| Application | Addition Ratio (in A part) | Mix Viscosity (25°C) | Pot Life (25℃,1000g, time to reach 60℃) | Tg-DSC |
|---|---|---|---|---|
| Infusion | 13% | 180-220 cps | >300 mins | >76°C |
Equivalent Mechanical Performance to Commercial Epoxy Resin
| Property | SWANCOR 2511 | EzCiclo RB511 | Test Method |
|---|---|---|---|
| Tensile Strength (MPa) | 67.05 | 67.70 | ISO 527 |
| Tensile Modulus (MPa) | 3,011 | 3,084 | ISO 527 |
| Elongation at break (%) | 7.24 | 7.70 | ISO 527 |
| Flexural Strength (MPa) | 116 | 110 | ISO 178 |
| Flexural Modulus (MPa) | 3,057.30 | 3034 | ISO 178 |
| Impact Strength (kJ/㎡) | 82.47 | 91.40 | ISO 179-1 |
